Установкa Thermo King схема TERMINAL 2 – 257G6
Обновление от: 3/7/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-9740 | RAIL (DIN) | 1 | |
| 51-2030 | RIVET - rail | A/R | ||
| 2 | 91-6465 | CLAMP | 2 | |
| 3 | 42-618 | RELAY | 1 | |
| 4 | 41-4725 | BREAKER - circuit (3.2 amp) | 1 | |
| 5 | 41-2931 | BLOCK - contact, auxiliary | 1 | |
| 6 | 42-619 | SWITCH - fuse | 1 | |
| 7 | 41-5901 | BLOCK - contact | 1 | |
| 8 | 41-3888 | CONTACTOR (11kW) | 1 | |
| 9 | 42-1019 | CAGE SPRING - terminal block | 1 | |
| 10 | 42-613 | FUSE (80amp, 500V) | 1 |
