Установкa Thermo King схема MATING CONNECTORS – 257A9
Обновление от: 2/9/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 42-385 | CONNECTOR - low voltage | 1 | |
| 2 | 41-5927 | HOUSING - connector | 1 | |
| 3 | 41-5928 | FRAME - fixing | 1 | |
| 4 | 41-5523 | COVER - connector, female | 1 | |
| 5 | 51-687 | BUSHING - cable | 1 | |
| 41-5619 | WASHER - sealing | 1 | ||
| 6 | 40-1039 | CONNECTOR - high voltage | 1 | |
| 7 | 41-5617 | HOUSING - connector | 1 | |
| 8 | 41-5618 | CORE - connector (3-pin) | 1 | |
| 9 | 51-1307 | SEAL - cable | 1 | |
| 10 | 40-1040 | CONNECTOR - communication | 1 | |
| 11 | 41-6917 | HOUSING - connector | 1 | |
| 12 | 41-6918 | CORE - connector (25-pin) | 1 | |
| 13 | 51-709 | BUSHING - cable | 1 | |
| 41-5619 | WASHER - sealing | 1 |
