Установкa Thermo King схема MAIN HARNESS – 256A5
Обновление от: 4/14/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 42-177 | HARNESS - main | 1 | |
| 2 | 41-9350 | RECEPTACLE - 23-pin (J1) | 1 | |
| 41-2457 | TERMINAL - socket | 14 | ||
| 44-9602 | PIN - sealing | 9 | ||
| 3 | 44-5719 | CONNECTOR - 8-pin | 1 | |
| 44-5630 | TERMINAL | 6 | ||
| 4 | 44-6451 | CONNECTOR - 1-pin | 1 | |
| 5 | 41-5710 | PLUG - 4-pin | 1 | |
| 33-3909 | GASKET - 4-pin connector | 1 | ||
| 44-9587 | SOCKET (18 ga) | 3 | ||
| 6 | 44-5219 | CONNECTOR - 2-pin | 1 | |
| 7 | 41-4468 | TERMINAL - ring (#8 yellow, 10-12 ga) | 1 | |
| 8 | 44-2792 | TERMINAL - ring (#8 yellow) | 2 | |
| 9 | 44-9585 | PLUG - 2-pin (w/ seal, see 112D9) | 3 | |
| 10 | 44-2788 | TERMINAL - fork (22-16 ga red) | 4 | |
| 11 | 41-4857 | PLUG - 1-pin (glow plug) | 1 | |
| 44-9836 | SOCKET (12-14 ga) | 1 | ||
| 12 | 44-9631 | CONNECTOR - 3-pin (w/ seal, see 112D9) | 1 | |
| 13 | 44-9589 | RECEPTACLE - 2-pin (see 112D9) | 1 | |
| 14 | 44-2793 | TERMINAL - ring (1/4 yellow) | 5 | |
| 15 | 44-8920 | CONNECTOR - 6-pin (w/ seal, see 112D9) | 3 | |
| 16 | 44-8914 | RECEPTACLE - 6-pin (see 112D9) | 2 | |
| 17 | 41-7419 | SWITCH - maintenance | 1 | |
| 18 | 44-1031 | TERMINAL - ring (22-16 ga, red 5/16) | 1 | |
| 19 | 41-7619 | COVER - terminal (starter) | 1 | |
| 41-7620 | TERMINAL | 1 | ||
| 41-8822 | SEAL - connector | 1 | ||
| 20 | 41-5436 | SENSOR | 2 | |
| 21 | 42-180 | TERMINAL - F | 1 | |
| 22 | 44-9607 | CONNECTOR - alternator (sense & exc) | 1 |
