Установкa Thermo King схема FILTER – 254B8
Обновление от: 11/15/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-9781 | FILTER | 1 | |
| 55-7172 | SCREW - filter | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-8893 | FLATWASHER | 4 | ||
| 55-7373 | NUT - captive | 4 | ||
| 2 | 92-9415 | PLATE | 1 | |
| 55-5130 | RIVET - plate | 2 | ||
| 3 | 55-2993 | LOCKWASHER | 2 | |
| 4 | 55-7075 | FLATWASHER | 2 | |
| 5 | 55-7354 | NUT | 1 | |
| 6 | 55-7042 | LOCKNUT | 1 | |
| 7 | 92-9416 | COVER | 1 | |
| 55-7664 | SCREW - cover | 4 | ||
| 55-7861 | LOCKWASHER | 4 | ||
| 55-7089 | FLATWASHER | 4 | ||
| 55-7866 | NUT - captive | 4 | ||
| 8 | 51-1400 | BUSHING - cable | 1 | |
| 55-9711 | LOCKNUT | 1 | ||
| 41-5619 | WASHER - sealing | 1 | ||
| 9 | 42-294 | HOUSING | 1 | |
| 55-7664 | SCREW - housing | 4 | ||
| 55-7861 | LOCKWASHER | 4 | ||
| 51-1181 | NUT - captive, closed | 4 | ||
| 10 | 42-293 | CAP | 1 | |
| 11 | 99-3281 | MOUNT - bandwrap | 4 | |
| 55-5130 | RIVET - mount | 4 | ||
| 55-2330 | BANDWRAP | 4 | ||
| 12 | 51-1631 | STRAP - cable | 4 | |
| 13 | 99-7834 | NAMEPLATE - Caution High Voltage | 2 |
