Установкa Thermo King схема COMPRESSOR – 253D5
Обновление от: 9/21/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-1031 | COMPRESSOR | 1 | |
| 55-7339 | NUT - compressor | 4 | ||
| 51-953 | FLATWASHER | 4 | ||
| 2 | 92-9314 | JUNCTION - compressor | 1 | |
| 56-3027 | SCREW - junction | 2 | ||
| 55-3008 | WASHER - sealing | 2 | ||
| 55-4526 | NUT - captive | 2 | ||
| 3 | 92-561 | COVER | 1 | |
| 55-9349 | SCREW - cover | 4 | ||
| 55-7861 | LOCKWASHER | 4 | ||
| 55-7697 | FLATWASHER | 4 | ||
| 55-7866 | NUT - captive | 4 | ||
| 4 | 33-3282 | SEALING | 1 | |
| 5 | 55-9555 | BUSHING - cable | 1 | |
| 51-691 | WASHER - sealing | 1 | ||
| 55-9559 | LOCKNUT | 1 | ||
| 6 | 91-7846 | NAMEPLATE - R407c | 1 | |
| 7 | 99-7834 | NAMEPLATE - Caution High Voltage | 1 |
