Установкa Thermo King схема HOSES AND FITTINGS ATH. SPLIT W/ 2 X TM31 (KIT 702651) – 252H9
Обновление от: 6/30/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-3473 | ADAPTER - tube | 6 | |
| 2 | 61-3108 | ADAPTER - tube | 6 | |
| 3 | 61-3947 | ADAPTER - assy (5/8) | 6 | |
| 4 | 61-5240 | ADAPTER - assy (3/4) | 6 | |
| 5 | 51-857 | NUT | 6 | |
| 6 | 51-858 | NUT | 6 | |
| 7 | 33-2848 | O-RING (9/16 id) | 10 | |
| 8 | 33-2847 | O-RING (11/16 id) | 10 | |
| 9 | 61-5536 | FITTING - UNS 1 1/16-14 | 1 | |
| 10 | 61-5537 | FITTING - UNF 7/8-14 | 1 | |
| 11 | 61-5545 | FITTING - UNS 1 1/16-14 | 1 | |
| 12 | 61-5551 | FITTING - UNF 7/8-14 | 1 | |
| 13 | 92-726 | HOSE #16, 1 M | 2 | |
| 14 | 61-5674 | HOSE #12, 1 M | 2 |
