Установкa Thermo King схема COVERS AND CONDENSER FANS – 250C4
Обновление от: 4/7/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8681 | COVER - condenser (3 fans) | 1 | |
| 55-5130 | SCREW - covers | A/R | ||
| 51-871 | WASHER - covers | A/R | ||
| 55-6997 | NUT - captive | A/R | ||
| 2 | 92-8900 | GRILLE - condenser | 2 | |
| 3 | 33-4765 | INSULATION - condenser | 1 | |
| 4 | 78-1780 | FAN - condenser | 3 | |
| 5 | 98-5425 | GUARD - fan | 3 | |
| 55-8464 | SCREW | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 6 | 92-8901 | STRIP - fan | 13 | |
| 55-7373 | NUT - captive | 13 | ||
| 7 | 98-8682 | COVER - evaporator blower | 2 | |
| 8 | 33-4766 | INSULATION - cover | 1 | |
| 55-7372 | SCREW - cover (7 per side) | 14 | ||
| 51-871 | WASHER - sealing | 14 | ||
| 55-7373 | NUT - captive | 14 | ||
| 9 | 98-8683 | SPOILER - center | 2 | |
| 55-7372 | SCREW - spoiler | 4 | ||
| 51-871 | WASHER - sealing | 4 | ||
| 10 | 92-8903 | SPOILER - side | 2 | |
| 11 | 92-8904 | SPOILER - side | 2 | |
| 92-1217 | NUTSTRIP | 4 | ||
| 55-3035 | RIVET - nutstrip | 8 | ||
| 55-7372 | SCREW - spoiler | 4 | ||
| 12 | 92-8905 | BRACKET - spoiler | 2 | |
| 13 | 92-8906 | BRACKET - spoiler | 2 | |
| 55-6997 | NUT - captive | 4 | ||
| 14 | 92-8902 | BRACKET - unit lifting | 4 | |
| 55-5130 | SCREW - bracket | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 |
