Установкa Thermo King схема HARNESS MASTER CONTROL – 250C0
Обновление от: 4/10/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-9776 | HARNESS - master control | 1 | |
| 2 | 41-3856 | CONNECTOR - female (18-pin) | 1 | |
| 41-4247 | RECEPTACLE | 11 | ||
| 3 | 44-5838 | CONNECTOR - tower (2-pin, see 115D14) | 2 | |
| 4 | 44-5835 | CONNECTOR - shroud (2-pin, see 115D14) | 1 | |
| 5 | 44-6959 | CONNECTOR - tower (3-pin, see 115D14) | 1 | |
| 6 | 44-1031 | TERMINAL - ring | 5 | |
| 7 | 41-8510 | CONNECTOR - female (9-pin) | 1 | |
| 8 | 41-8509 | CONNECTOR - male (9-pin) | 1 | |
| 9 | 41-8511 | CONNECTOR - male (6-pin) | 1 | |
| 41-8512 | TERMINAL - female | 13 | ||
| 41-8513 | TERMINAL - male | 9 |
