Установкa Thermo King схема DISPLAY PANEL - DRIVER IntelligAIRE III – 246H2
Обновление от: 7/7/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2339 | MODULE - display IntelligAIRE III | 1 | |
| 55-3256 | SCREW - display | 4 | ||
| 55-3013 | FLATWASHER | 4 | ||
| 55-5754 | NUT - stop | 4 | ||
| 2 | 92-8549 | BRACKET - support | 1 | |
| 55-2957 | SCREW - bracket | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 3 | 41-9432 | HARNESS- display IntelligAIRE III (w/resistor) | 2 | |
| 4 | 41-654 | CONNECTOR - in line (4-pin) | 1 | |
| 5 | 41-4537 | RESISTOR (120 ohm 1/2 w) | 1 | |
| 41-1807 | SOCKET (18-24 ga) | 2 | ||
| 41-4496 | SOCKET (16 ga) | 2 | ||
| 6 | 41-8221 | PLUG - in line (4-pin) | 1 | |
| 651-148 | TERMINAL - pin (18-24 ga) | 4 | ||
| 7 | 41-9527 | HARNESS - display IntelligAIRE III | 1 | |
| 8 | 41-654 | CONNECTOR - in line (4-pin) | 1 | |
| 41-1807 | SOCKET (18-24 ga) | 4 | ||
| 9 | 41-8221 | PLUG - in line (4-pin) | 1 | |
| 651-148 | TERMINAL - pin (18-24 ga) | 4 |
