Установкa Thermo King схема REFRIGERATION - EVAPORATOR CLAMPS & MOUNTING (SLAVE) – 246E1
Обновление от: 7/26/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-7143 | CLAMP - tube (.562 id) | 2 | |
| 91-758 | CLAMP - tube (.625 id) | 1 | ||
| 91-372 | CLAMP - tube (.75 id) | 1 | ||
| 55-7013 | CLAMP - tube (.875 id) | 1 | ||
| 55-3675 | SCREW - clamp (1.75 in long) | 3 | ||
| 55-3462 | SCREW - clamp (2.0 in long) | 2 | ||
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-1800 | LOCKWASHER | 5 | ||
| 55-2086 | FLATWASHER | 5 | ||
| 2 | 55-4552 | CLAMP - exp valve | 2 | |
| 55-2957 | SCREW - clamp | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 3 | 92-1741 | BRACKET - expansion valve (roadside) | 1 | |
| 4 | 92-1742 | BRACKET - expansion valve (curbside) | 1 | |
| 55-2957 | SCREW - bracket | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-6526 | INSERT - threaded | 4 | ||
| 5 | 92-2768 | BRACKET - liquid tube | 1 | |
| 55-2957 | SCREW - bracket | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 6 | 92-1345 | BRACKET - sight glass | 1 | |
| 55-2957 | SCREW - bracket | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 55-4953 | NUT - lock | 1 | ||
| 7 | 92-3265 | SUPPORT - clamp | 1 | |
| 8 | 91-5143 | CLAMP - tube | 2 | |
| 91-6158 | PLATE - clamp | 1 | ||
| 55-4811 | SCREW - clamp | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT - lock | 2 | ||
| 9 | 55-4488 | HANGER - valve | 1 | |
| 55-2957 | SCREW - hanger mounting | 1 | ||
| 55-3462 | SCREW - hanger clamp | 1 | ||
|
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2086 | FLATWASHER | 3 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-4953 | NUT | 1 |
