Установкa Thermo King схема COMPRESSOR MUFFLER KIT – 245H1
Обновление от: 2/9/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1641 | MUFFLER - complete | 1 | |
| 66-9201 | MUFFLER - refrigerant | 1 | ||
| 66-5247 | ADAPTER - muffler (#16) | 2 | ||
| 55-4621 | NUT | 1 | ||
| 2 | 55-9095 | CLAMP | 2 | |
| 3 | 33-3165 | O-RING - muffler | 1 | |
| 4 | 33-3191 | GASKET - ring | 2 | |
| 5 | 61-2152 | HOSE | A/R | |
| 6 | 55-9775 | FITTING | 1 | |
| 7 | 51-582 | FITTING (#16, 0 deg) | 1 |
