Установкa Thermo King схема REFRIGERATION - EVAPORATOR – 245G9
Обновление от: 2/9/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-705 | TUBE - adapter to valve | 1 | |
| 55-8749 | ADAPTER - bulkhead | 1 | ||
| 2 | 33-566 | O-RING | 1 | |
| 3 | 66-2104 | VALVE - shutoff | 2 | |
| 4 | 66-9979 | TUBE - assembly | 2 | |
| 66-9913 | TUBE | 2 | ||
| 55-6396 | NUT - shoulder | 2 | ||
| 55-6356 | SHOULDER | 2 | ||
| 5 | 66-9352 | DEHYDRATOR - filter drier | 1 | |
| 66-9352 OEM | Фильтр-осушитель | 6 350 ₽ |
|
|
| 6 | 55-2688 | CLAMP - dehydrator | 1 | |
| 7 | 61-1979 | TUBE - valve to tee | 1 | |
| 8 | 55-6507 | TEE (5/8 x 5/8 x 3/8) | 1 | |
| 9 | 61-1980 | TUBE - tee to plate | 1 | |
| 10 | 61-706 | TUBE - tee to sightglass | 1 | |
| 11 | 91-758 | CLAMP - tube | 1 | |
| 55-7088 | SCREW - clamp | 1 | ||
| 55-7033 | FLATWASHER | 1 | ||
| 55-7404 | LOCKWASHER | 1 | ||
| 55-7367 | NUT | 1 | ||
| 12 | 66-9856 | INDICATOR - liquid (sightglass) | 1 | |
| 13 | 66-8454 | VALVE - expansion | 1 | |
| 14 | 61-1981 | TUBE - equalizer | 1 | |
| 15 | 67-1916 | COIL - evaporator (1000) | 1 | |
| 55-7035 | SCREW - coil | 4 | ||
| 55-7172 | SCREW - coil | 2 | ||
| 55-7170 | LOCKWASHER | 12 | ||
| 55-7075 | FLATWASHER | 12 | ||
| 33-2411 | INSULATION - coil | 2 | ||
| 55-7373 | NUT - CAPTIVE | 6 | ||
| 33-452 | GROMMET | 2 | ||
| 55-6994 | SCREW | 6 | ||
| 16 | 11-8867 | FILTER - air | 4 | |
| 17 | 61-1982 | TUBE - coil to adapter | 1 | |
| 18 | 92-2016 | TUBE - sponge rubber (5ft) | A/R | |
| 19 | 55-9705 | VALVE - body | 1 | |
| 20 | 11-7777 | CORE - valve | 1 | |
| 21 | 55-5672 | VALVE - cap | 1 | |
| 22 | 61-1983 | ADAPTER - plate assembly | 1 | |
| 55-7340 | SCREW - plate | 5 | ||
| 55-7171 | LOCKWASHER | 5 | ||
| 55-8221 | FLATWASHER | 5 | ||
| 23 | 92-2015 | TUBE - sponge rubber (5ft) | A/R | |
| 24 | 61-1984 | TUBE - adapter | 1 | |
| 25 | 91-3542 | TUBE - sponge rubber (5ft) | A/R | |
| 26 | 61-1985 | TUBE | 1 | |
| 27 | 66-6840 | ADAPTER - bulkhead | 1 | |
| 28 | 33-3165 | O-RING - discharge | 2 | |
| 29 | 33-3166 | O-RING - suction | 1 | |
| 30 | 33-1015 | O-RING - liquid | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 31 | 55-5741 | LOCKWASHER | 1 | |
| 32 | 55-5740 | NUT | 1 | |
| 33 | 55-6843 | LOCKWASHER | 1 | |
| 34 | 55-6811 | NUT | 1 |
