Установкa Thermo King схема REFRIGERATION COMPONENTS – 245F6
Обновление от: 8/13/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 51-1911 | FLANGE - complete | 1 | |
| 55-5427 | SCREW - flange | 2 | ||
| 2 | 51-577 | ADAPTER - solder | 1 | |
| 3 | 55-9186 | FLANGE | 1 | |
| 4 | 92-8932 | BRACKET - flange | 1 | |
| 55-6994 | SCREW - bracket | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 5 | 61-5494 | TUBE - suction | 1 | |
| 6 | 203-391 | SEALER - tape | 1 | |
| 7 | 66-6996 | FITTING - saddle | 2 | |
| 8 | 41-1501 | SWITCH - hpco (ClimaAIRE system) | 1 | |
| 41-4146 | SWITCH - hpco (CANAIRE system) | 1 | ||
| 9 | 11-2886 | VALVE - assy (CANAIRE system) | 1 | |
| 10 | 55-7213 | BODY - valve | 1 | |
| 11 | 11-7777 | VALVE | 1 | |
| 55-5672 | CAP - valve | 1 | ||
| 12 | 41-5220 | SWITCH - cps (ClimaAIRE system) | 1 | |
| 13 | 61-2059 | VALVE | 1 | |
| 14 | 41-5781 | TRANSDUCER - pressure (CANAIRE system) | 1 | |
| 41-5781 OEM | Трансдюсер, V-Series | 32 730 ₽ |
|
|
|
10-41-5781 | Трансдюсер, V-Series | 3 820 ₽ |
|
| 15 | 61-5495 | TUBE (narrow unit) | 1 | |
| 61-5496 | TUBE (wide unit) | 1 | ||
| 16 | 91-372 | CLAMP - tube | 1 | |
| 55-8993 | SCREW - clamp | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 17 | 61-5476 | TUBE - reduction | 1 | |
| 18 | 306-1802 | Y-TUBE | 1 | |
| 19 | 61-5480 | TUBE | 1 | |
| 20 | 61-5481 | TUBE | 1 | |
| 21 | 55-8951 | SHOULDER | 2 | |
| 22 | 55-8950 | NUT - shoulder | 2 | |
| 23 | 33-566 | O-RING | 2 | |
| 24 | 67-2401 | COIL - condenser | 2 | |
| 55-6994 | SCREW - coil | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 55-7373 | NUT - captive | 8 | ||
| 25 | 33-1015 | O-RING | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 26 | 55-8268 | SHOULDER | 2 | |
| 27 | 55-6358 | NUT - shoulder | 2 | |
| 28 | 61-5477 | TUBE | 2 | |
| 29 | 61-5478 | TUBE | 1 | |
| 30 | 61-5479 | TUBE | 1 | |
| 31 | 67-2608 | TANK - receiver | 1 | |
| 32 | 55-2688 | CLAMP - tank | 1 | |
| 33 | 61-5497 | TUBE - tank (narrow unit) | 1 | |
| 61-5498 | TUBE - tank (wide unit) | 1 | ||
| 34 | 55-3295 | FITTING - saddle | 1 | |
| 35 | 66-7392 | VALVE - relief, complete | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 36 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 37 | 33-3669 | BUSHING - cable | 2 | |
| 38 | 66-1188 | INDICATOR - liquid (sight glass) | 1 | |
| 39 | 91-758 | CLAMP - tube | 1 | |
| 55-8316 | SCREW - clamp | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 40 | 61-5556 | TUBE | 1 | |
| 41 | 55-6838 | NUT - shoulder | 2 | |
| 42 | 55-6837 | SHOULDER | 2 | |
| 43 | 33-566 | O-RING | 2 | |
| 44 | 66-8344 | FILTER - drier (dehydrator) | 1 | |
| 45 | 92-8859 | HOLDER - filter | 1 | |
| 55-7172 | SCREW - holder | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-8893 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 46 | 61-5499 | TUBE (narrow unit) | 1 | |
| 61-5500 | TUBE (wide unit) | 1 | ||
| 47 | 61-5501 | TUBE - connection (unit w/ FB) | 1 | |
| 61-5502 | TUBE - connection (unit w/o FB) | 1 | ||
| 48 | 55-2181 | TEE (1/2 x 1/2 x 3/8, only unit w/ FB) | 1 | |
| 49 | 61-5482 | TUBE - front box (only for narrow unit w/ FB) | 1 | |
| 61-5483 | TUBE - front box (only for wide unit w/ FB) | 1 | ||
| 50 | 92-8860 | PLATE - adapter holder (unit w/ FB) | 1 | |
| 92-8861 | PLATE (unit w/o FB) | 1 | ||
| 55-5130 | RIVET - plate | 3 | ||
| 51 | 61-3643 | ADAPTER (only unit w/ FB) | 1 | |
| 52 | 33-1461 | O-RING (only unit w/ FB) | 1 | |
| 53 | 92-120 | INSERT - plug (only unit w/ FB) | 1 | |
| 54 | 92-121 | NUT (only unit w/ FB) | 1 | |
| 55 | 61-5484 | TUBE | 1 | |
| 56 | 55-6222 | TEE (3/8 x 3/8 x 1/2) | 1 | |
| 57 | 61-5509 | TUBE (narrow unit) | 1 | |
| 61-5510 | TUBE (wide unit) | 1 | ||
| 58 | 61-5511 | TUBE (narrow unit) | 1 | |
| 61-5512 | TUBE (wide unit) | 1 | ||
| 59 | 67-2597 | COIL - evaporator | 1 | |
| 61-863 | VALVE - thermostatic expansion R134a | 1 | ||
| 67-2599 | COIL - evaporator/heater | 1 | ||
| 61-863 | VALVE - thermostatic expansion R134a | 1 | ||
| 60 | 67-2598 | COIL - evaporator | 1 | |
| 61-863 | VALVE - thermostatic expansion R134a | 1 | ||
| 67-2600 | COIL - evaporator/heater | 1 | ||
| 61-863 | VALVE - thermostatic expansion R134a | 1 | ||
| 55-5130 | RIVET - coil | 4 | ||
| 203-534 | TAPE - insulating | A/R | ||
| 61 | 92-8798 | FILTER - evaporator | 2 | |
| 62 | 92-3540 | CLIP | 4 | |
| 63 | 92-8801 | FILTER - evaporator (unit w/o heater) | 2 | |
| 92-8802 | FILTER - evaporator (unit w/ heater) | 2 | ||
| 64 | 61-5513 | TUBE - equalizer (narrow unit) | 1 | |
| 61-5514 | TUBE - equalizer (wide unit) | 1 | ||
| 65 | 61-5515 | TUBE - equalizer (narrow unit) | 1 | |
| 61-5516 | TUBE - equalizer (wide unit) | 1 | ||
| 66 | 61-5487 | TUBE (narrow unit) | 1 | |
| 61-5488 | TUBE (wide unit) | 1 | ||
| 67 | 61-5485 | TUBE (narrow unit) | 1 | |
| 61-5486 | TUBE (wide unit) | 1 | ||
| 68 | 55-6508 | TEE (7/8 x 7/8 x1-1/8) | 1 | |
| 69 | 61-5489 | TUBE (narrow unit) | 1 | |
| 61-5490 | TUBE (wide unit) | 1 | ||
| 70 | 61-2059 | VALVE | 1 | |
| 71 | 41-4147 | SWITCH - lpco (CANAIRE system) | 1 | |
| 41-4309 | SWITCH - lpco (ClimaAIRE system) | 1 | ||
| 72 | 55-9186 | FLANGE | 1 | |
| 73 | 51-374 | ADAPTER - solder (1 1/8")" | 1 | |
| 74 | 91-9143 | FLANGE - complete | 1 | |
| 55-5427 | SCREW - flange | 2 | ||
| 75 | 51-2242 | CLAMP | 4 |
