Установкa Thermo King схема BASE & COVERS – 243G4
Обновление от: 5/4/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-8422 | PANEL - base | 1 | |
| 2 | 92-7667 | PANEL - side | 1 | |
| 3 | 92-7666 | PANEL - side | 1 | |
| 4 | 92-7668 | PANEL - front | 1 | |
| 5 | 92-7670 | PANEL - side | 1 | |
| 6 | 92-7669 | PANEL - side | 1 | |
| 7 | 92-7673 | PANEL - front | 1 | |
| 8 | 92-7674 | COVER - top | 1 | |
| 55-5130 | RIVET - panels & cover | A/R | ||
| 9 | 92-7671 | COVER - service | 1 | |
| 55-7340 | SCREW - cover | 4 | ||
| 51-130 | LOCKWASHER | 4 | ||
| 55-8375 | NUT - captive | 4 | ||
| 10 | 51-264 | NOZZLE - connecting | 4 | |
| 11 | 92-3402 | STRIP - polyester | A/R | |
| 12 | 99-4976 | STRIP - neoprene | A/R |
