Установкa Thermo King схема CONTROLLER #1 – 243F5
Обновление от: 7/27/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-7617 | COVER | 1 | |
| 2 | 41-6097 | PANEL - control | 1 | |
| 3 | 55-9623 | STUD - self clinching (M5) | 4 | |
| 4 | 55-7034 | NUT - hexstop | 3 | |
| 5 | 51-310 | NUT - acorn (plastic) | 1 | |
| 6 | 41-896 | RELAY | 7 | |
| 7 | 44-9344 | FUSE (15 amp) | 4 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 8 | 41-1292 | FUSE (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 9 | 41-2978 | FUSE (20 amp) | 2 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 10 | 41-6098 | SUPRESSOR - voltage | 1 | |
| 51-888 | STUD - self clinching (M3) | 1 | ||
| 55-7830 | FLATWASHER | 1 | ||
| 55-9057 | LOCKWASHER | 1 | ||
| 55-7749 | NUT | 1 | ||
| 11 | 55-9367 | STUD - terminal | 1 | |
| 55-3238 | LOCKWASHER | 3 | ||
| 55-8955 | FLATWASHER | 4 | ||
| 55-448 | FLATWASHER | 2 | ||
| 55-8631 | WASHER (nylon, w/shoulder) | 1 | ||
| 55-8693 | WASHER (nylon) | 1 | ||
| 305-1653 | NUT | 4 | ||
| 12 | 55-9191 | STUD - terminal | 1 | |
| 55-3672 | LOCKWASHER | 1 | ||
| 55-448 | FLATWASHER | 4 | ||
| 55-3066 | LOCKWASHER | 2 | ||
| 55-9189 | NUT | 4 | ||
| 13 | 51-1631 | STRAP - cable | 6 | |
| 14 | 92-7618 | INSULATION | 1 | |
| 15 | 92-3279 | RUBBER - profile | A/R |
