Установкa Thermo King схема LIFT GATE CONTROL BOX (701856) – 242B8
Обновление от: 3/12/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 40-1036 | KIT - lift gate control box | 1 | ||
| 1 | 92-8243 | BOX - control | 1 | |
| 55-8711 | INSERT - threaded | 2 | ||
| 2 | 55-2977 | SCREW - ground | 1 | |
| 55-2086 | FLATWASHER | 2 | ||
| 55-2993 | FLATWASHER (int th) | 3 | ||
| 55-1801 | NUT | 2 | ||
| 3 | 41-3990 | SOLENOID (12V, 100A) | 1 | |
| 55-1587 | SCREW - solenoid | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-1801 | NUT | 2 | ||
| 4 | 44-5537 | SOCKET - relay | 2 | |
| 55-3027 | SCREW - socket | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 5 | 41-895 | RELAY - mini | 1 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 6 | 44-8680 | FILTER - power | 1 | |
| 55-3027 | SCREW - filter | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 7 | 41-3074 | HOLDER - fuse | 1 | |
| 30-41-3074 | Гнездо предохранителя | 600 ₽ |
|
|
| 8 | 41-3077 | FUSE - mini (3 amp) | 1 | |
| 30-41-3077 | Предохранитель 32V 3А | 520 ₽ |
|
|
| 9 | 55-5919 | CONNECTOR - cable grip | 2 | |
| 10 | 55-2636 | NUT - connector | 2 | |
| 11 | 92-8244 | COVER - box | 1 | |
| 33-2467 | GASKET - cover (25 ft) | A/R | ||
| 55-1587 | SCREW - cover | 2 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 12 | 92-4706 | SLEEVING - cable (split) | A/R | |
| 13 | 41-8617 | CONNECTION - terminal | 1 | |
| 14 | 41-8618 | FUSE (60 amp) | 1 | |
| 15 | 41-8076 | HOLDER - fuse | 1 | |
| 16 | 40-1012 | CABLE - battery (30 ft) | 1 | |
| 40-1013 | CABLE - battery (60 ft) | 1 | ||
| 17 | 41-5672 | TERMINAL - lug (3/8) | 2 |
