Установкa Thermo King схема INSTALLATION COMPONENTS (701083) – 240A6
Обновление от: 8/21/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-4658 | ClimaAIRE II (see 184F9) | 1 | |
| 2 | 98-7688 | CHANNEL - support, upper | 1 | |
| 3 | 66-1273 | VALVE - check | 2 | |
| 4 | 98-7687 | GRILLE | 1 | |
| 5 | 45-2188 | HARNESS - compressor to evap (for connectors see 115D14) | 1 | |
| 44-6959 | CONNECTOR - tower (3-pin) | 1 | ||
| 44-5836 | TERMINAL - male (14-16 ga) | 3 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 3 | ||
| 44-9569 | CONNECTOR - shroud (3-pin) | 1 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 2 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 3 | ||
| 6 | 41-9092 | HARNESS - boost pump | 1 | |
| 44-5838 | CONNECTOR - tower (2-pin) | 1 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 2 | ||
| 44-6324 | SEAL - cable (blue, 12-14 ga) | 2 | ||
| 44-5835 | CONNECTOR - shroud (2-pin) | 1 | ||
| 44-5836 | TERMINAL - male (14-16 ga) | 2 | ||
| 44-6324 | SEAL - cable (blue, 12-14 ga) | 2 | ||
| 7 | 45-2189 | HARNESS - driver to evap | 1 | |
| 8 | 41-661 | CONNECTOR - socket | 1 | |
| 41-1807 | TERMINAL (18-24 ga) | 12 | ||
| 9 | 41-6160 | CONNECTOR (female, 14-pin) | 1 | |
| 651-148 | TERMINAL - pin (18-24 ga) | 12 | ||
| 10 | 44-6381 | CONNECTOR (female, 1 term) | 1 | |
| 44-5066 | TERMINAL | 1 | ||
| 11 | 45-2187 | HARNESS - condenser to evap (for connectors see 115D14) | 1 | |
| 12 | 44-7881 | CONNECTOR - tower (4-pin) | 1 | |
| 44-5839 | TERMINAL - female (14-16 ga) | 4 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 4 | ||
| 13 | 44-7872 | CONNECTOR - tower (6-pin) | 1 | |
| 44-5839 | TERMINAL - female (14-16 ga) | 6 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 6 | ||
| 14 | 44-7880 | CONNECTOR - shroud (4-pin) | 1 | |
| 44-5836 | TERMINAL - male (14-16 ga) | 4 | ||
| 44-6324 | SEAL - cable (blue, 12-14 ga) | 4 | ||
| 15 | 44-8294 | CONNECTOR - shroud (6-pin) | 1 | |
| 44-5836 | TERMINAL - male (14-16 ga) | 6 | ||
| 44-6324 | SEAL - cable (blue, 12-14 ga) | 6 | ||
| 16 | 67-1711 | HOSE - refrigeration, #12 (cut to 2 ft) | A/R | |
| 17 | 98-6722 | HOSE (0.75 in x 1.00 in od, cut to 180 ft) | A/R | |
| 18 | 92-6291 | FILTER - air | 1 | |
| 19 | 41-4157 | SENSOR - temperature | 1 | |
| 44-5835 | CONNECTOR - shroud (2-pin) | 1 | ||
| 44-5883 | TERMINAL - male (18-20 ga) | 2 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 2 | ||
| 20 | 41-8930 | HARNESS - driver to evaporator | 1 | |
| 21 | 41-661 | CONNECTOR (14-pin) | 1 | |
| 41-1807 | TERMINAL (18-24 ga) | 14 | ||
| 22 | 41-6160 | CONNECTOR (14-pin) | 1 | |
| 651-148 | TERMINAL - pin (18-24 ga) | 14 | ||
| 23 | 41-650 | CONNECTOR (18-pin) | 1 | |
| 41-1807 | TERMINAL (18-24 ga) | 18 | ||
| 24 | 44-5838 | CONNECTOR - tower (2-pin) | 1 | |
| 44-5884 | TERMINAL - female (18-20 ga) | 2 | ||
| 44-8681 | SEAL - cable (red, 18-20 ga) | 2 | ||
| 25 | 44-6381 | CONNECTOR - female (1-pin) | 1 | |
| 44-5066 | TERMINAL - fingrip (14-18 ga) | 1 |
