Установкa Thermo King схема MAIN HARNESS V-100/200/300 20 & 50 – 236F9
Обновление от: 8/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8340 | HARNESS - condenser ( V-100 20 & 50) | 1 | |
| 42-1293 | HARNESS - condenser ( V-100 20 & 50, with fuse) | 1 | ||
| 2 | 41-5794 | CONNECTOR - 24-pin (female, C1, control box) | 1 | |
| 41-5792 | WEDGE - 24-pin | 1 | ||
| 41-6506 | TERMINAL - 1.5 MM | 16 | ||
| 41-6541 | TERMINAL - 2.8 MM | 3 | ||
| 3 | 44-9600 | PLUG - 12-pin (male, C2, control box) | 1 | |
| 44-9601 | WEDGE - 12-pin | 1 | ||
| 44-9587 | SOCKET - 18 ga | 2 | ||
| 44-9593 | SOCKET - 14-16 ga | 8 | ||
| 4 | 41-5800 | HOLDER - relay (C1R & STDBR) | 2 | |
| 5 | 44-5537 | HOLDER - relay (BATR) | 1 | |
| 41-1760 | TERMINAL - fingrip (10-14 ga) | 2 | ||
| 41-6558 | TERMINAL - fingrip 6-10 ga) | 4 | ||
| 41-8931 | TERMINAL - fingrip (0.5-1 6.3) | 4 | ||
| 6 | 41-7856 | TERMINAL - ring (8/13) | 7 | |
| 7 | 41-280 | TERMINAL - fork (22-16, red) | 21 | |
| 41-4973 | TERMINAL - fork 12-10, yellow) | 1 | ||
| 8 | 41-9089 | TERMINAL - fingrip (blue) | 6 | |
| 9 | 41-9090 | TERMINAL - flag (1-2.5, female) | 2 | |
| 10 | 41-5799 | CONNECTOR - 3-pin (female) | 1 | |
| 41-7747 | TERMINAL | 3 | ||
| 41-5799 | SEAL - terminal | 3 | ||
| 11 | 44-5835 | CONNECTOR - 2-pin (female) | 6 | |
| 44-5883 | TERMINAL - male (18-20 ga) | 12 | ||
| 12 | 44-5838 | CONNECTOR - tower (2-pin) | 3 | |
| 44-5884 | TERMINAL - female (18-20 ga) | 2 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 4 | ||
| 13 | 44-7330 | CONNECTOR - shroud (1-pin) | 1 | |
| 41-8931 | TERMINAL - fingrip (0.5-1 6.3) | 2 | ||
| 14 | 41-5804 | CONNECTOR - 5-pin (cab controller) | 1 | |
| 41-5805 | RETAINER - 5-pin | 1 | ||
| 41-6451 | TERMINAL - 2.5 MM | 5 | ||
| 15 | 33-2656 | GROMMET | 1 | |
| 16 | 44-9589 | RECEPTACLE - 2-pin (liquid injection) | 1 | |
| 17 | 44-9585 | PLUG - 2-pin (solenoid) | 2 | |
| 18 | 42-962 | HOLDER - in-line fuse | 1 | |
| 42-964 | FUSE - (16 amp, 12V units) | 1 |
