Установкa Thermo King схема SLAVE CONTROL HARNESS – 235G8
Обновление от: 4/28/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8768 | HARNESS - slave control | 1 | |
| 2 | 41-4198 | CONNECTOR (10-pin, gray) | 1 | |
| 41-5054 | LOCK - secondary | 1 | ||
| 3 | 44-7872 | CONNECTOR - tower (6-pin, see 115D14) | 1 | |
| 4 | 41-4199 | CONNECTOR (8-pin) | 1 | |
| 41-5055 | LOCK - secondary | 1 | ||
| 5 | 41-4197 | CONNECTOR (10-pin, black) | 1 | |
| 41-5054 | LOCK - secondary | 1 | ||
| 41-7681 | TUBING - heat shrink (1-1/2 in lg) | 3 | ||
| 6 | 44-5838 | CONNECTOR - tower (2-pin) | 3 | |
| 7 | 41-4281 | CONNECTOR (6-pin) | 2 | |
| 41-4282 | CONNECTOR - wedge | 2 | ||
| 8 | 41-2973 | HOLDER - fuse | 3 | |
| 9 | 44-7881 | CONNECTOR - tower (4-pin) | 1 | |
| 10 | 44-7880 | CONNECTOR - 4-way (see 115D14) | 1 | |
| 11 | 44-5835 | CONNECTOR - 2-way (see 115D14) | 1 | |
| 12 | 44-2789 | TERMINAL - ring (blue 1/4, 14-16 ga) | 1 | |
| 13 | 44-2791 | TERMINAL - ring (blue #10, 14-16 ga) | 1 | |
| 14 | 41-4817 | CONNECTOR - liquid tite | 1 | |
| 15 | 41-5359 | WASHER - sealing | 1 | |
| 16 | 92-6109 | PLATE - harness | 1 | |
| 17 | 55-2635 | NUT - lock | 1 | |
| 18 | 44-2786 | TERMINAL - ring (3/8 blue, 16-14ga) | 1 | |
| 19 | 651-295 | TERMINAL - ring (6 blue, 16-14ga) | 1 | |
| 20 | 41-281 | TERMINAL - ring (6 red, 22-16ga) | 1 | |
| 21 | 41-280 | TERMINAL - fork (6 red, 22-16ga) | 17 | |
| 22 | 44-7245 | TERMINAL - ring (10 red, 22-16ga) | 4 |
