Установкa Thermo King схема HARNESS CONDENSER (78-1530 fans) – 233A2
Обновление от: 12/18/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-7387 | HARNESS - condenser (78-1530 & 78-1344 fans) | 1 | |
| 2 | 41-2767 | CONNECTOR - female (6-pin) | 1 | |
| 41-4247 | RECEPTACLE (.5mm) | 2 | ||
| 41-4248 | RECEPTACLE (1.5mm) | 1 | ||
| 3 | 41-3967 | CONNECTOR - female (6-pin) | 1 | |
| 44-9695 | TERMINAL - fingrip (14-18ga) | 6 | ||
| 4 | 41-3966 | CONNECTOR - female (3-pin) | 1 | |
| 44-9695 | TERMINAL - fingrip (14-18ga) | 3 | ||
| 5 | 44-5835 | CONNECTOR - shroud (2-pin, see 115D14) | 1 | |
| 6 | 44-2788 | TERMINAL - fork | 1 | |
| 44-7245 | TERMINAL - ring | 1 |
