Установкa Thermo King схема STRUCTURAL FRAME & COVER (819986) – 230H2
Обновление от: 11/10/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6691 | FRAME - assembly | 1 | |
| 2 | 92-7140 | PLATE - front | 1 | |
| 51-667 | FASTENER | 3 | ||
| 51-668 | PLATE - locking (fastener) | 3 | ||
| 3 | 33-3864 | STRIP | A/R | |
| 4 | 92-3045 | GRILLE - internal (bottom) | 1 | |
| 5 | 92-3046 | FILTER - air | 1 | |
| 6 | 92-3060 | GRILLE - external (top) | 1 | |
| 7 | 33-3931 | STRIP | A/R | |
| 8 | 92-3063 | COVER - heater | 1 | |
| 55-7826 | SCREW | 6 | ||
| 55-7089 | WASHER - flat | 6 | ||
| 55-7404 | WASHER - lock | 6 | ||
| 9 | 92-3065 | NOZZLE (63 mm) | 1 | |
| 55-1714 | RIVET | 4 | ||
| 10 | 92-3064 | BRACKET - servomotor | 1 | |
| 55-7089 | NUT | 4 | ||
| 55-7034 | WASHER | 4 | ||
| 11 | 51-670 | PLUG | 1 | |
| 92-3066 | VENTILATOR - plate | 1 | ||
| 55-7404 | WASHER - lock | 6 | ||
| 51-1547 | KNOB | 1 | ||
| 12 | 92-3066 | PLATE - ventilator | 1 | |
| 33-3864 | STRIP | A/R | ||
| 13 | 92-3061 | BRACKET - servomotor | 1 | |
| 55-7034 | NUT | 3 | ||
| 55-7089 | WASHER | 3 | ||
| 14 | 92-3062 | NOZZLE (50 mm) | 2 | |
| 55-1714 | RIVET | 8 |
