Установкa Thermo King схема COMPRESSOR CONNECTIONS & HOSES (KIT 800307) – 230E0
Обновление от: 7/29/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-4367 | TUBE - discharge | 1 | |
| 2 | 61-4368 | TUBE - suction | 1 | |
| 3 | 55-5741 | LOCKWASHER (#16) | 1 | |
| 4 | 55-5742 | LOCKWASHER (#20) | 1 | |
| 5 | 92-7130 | BRACKET - discharge | 1 | |
| 6 | 92-7131 | BRACKET - suction | 1 | |
| 7 | 55-7111 | NUT- bulkhead (#16) | 1 | |
| 8 | 55-9231 | NUT - bulkhead (#20) | 1 | |
| 9 | 33-2789 | WASHER - sealing brass | 3 | |
| 33-1785 | O-RING - (15/16) | 1 | ||
| 10 | 66-9483 | HOSE - discharge (#16 23.2 in ss) | 1 | |
| 11 | 66-9686 | HOSE - suction (#20 31.0 in ss) | 1 | |
| 12 | 33-1777 | O-RING - suction (1-3/16id) | 1 | |
| 13 | 55-5886 | ADAPTER - discharge (#16) | 1 | |
| 14 | 55-5887 | ADAPTER - suction (#20) | 1 |
