Установкa Thermo King схема HEATER – 229E4
Обновление от: 12/17/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2395 | HEATER | 1 | |
| 55-7172 | SCREW - heater | 5 | ||
| 55-6996 | LOCKWASHER | 5 | ||
| 55-7075 | FLATWASHER | 5 | ||
| 2 | 41-3791 | SWITCH - temperature | 1 | |
| 3 | 41-4728 | SWITCH - temperature | 1 | |
| 55-9195 | SCREW - switch | 4 | ||
| 55-7750 | LOCKWASHER | 4 | ||
| 55-7749 | NUT | 4 | ||
| 4 | 51-709 | BUSHING | 1 | |
| 41-5619 | WASHER - sealing | 1 | ||
| 55-9711 | LOCKNUT - bushing | 1 | ||
| 5 | 55-8137 | SCREW - ground | 1 | |
| 55-7085 | FLATWASHER | 2 | ||
| 55-7342 | LOCKWASHER | 1 | ||
| 55-7825 | NUT | 1 |
