Установкa Thermo King схема CONTROL BOX PANELS – 227H0
Обновление от: 2/9/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-6963 | BOX - weld assembly | 1 | |
| 55-7172 | SCREW - box to unit frame | 4 | ||
| 51-871 | WASHER - sealing | 4 | ||
| 51-1670 | NUT - captive, closed | 3 | ||
| 55-9837 | NUT - captive | 1 | ||
| 2 | 92-6964 | DOOR - box | 1 | |
| 3 | 92-5927 | LATCH | 2 | |
| 4 | 55-8137 | SCREW - ground | 1 | |
| 55-7085 | FLATWASHER | 2 | ||
| 55-7342 | LOCKWASHER | 1 | ||
| 55-7825 | NUT | 1 | ||
| 5 | 92-146 | RUBBER - extrusion | A/R | |
| 6 | 99-7834 | NAMEPLATE - Caution High Voltage | 1 | |
| 7 | 92-7253 | COVER - sealing | 2 |
