Установкa Thermo King схема COMPRESSOR – 227D3
Обновление от: 11/2/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-878 | COMPRESSOR - hermetic (220-240V) | 1 | |
| 41-5869 | CAPACITOR - run | 1 | ||
| 41-5870 | OVERLOAD - external | 1 | ||
| 92-3609 | COVER - electrical | 1 | ||
| 33-3947 | GASKET - electrical cover | 1 | ||
| 51-829 | NUT - electrical cover | 1 | ||
| 203-548 | OIL (1 liter can) | 1 | ||
| 2 | 92-6203 | SPACER | 4 | |
| 3 | 92-6204 | FLATWASHER | 4 | |
| 4 | 92-6205 | INSERT - pin | 4 | |
| 5 | 33-1213 | GROMMET (0.5 id) | 4 | |
| 6 | 92-3610 | BRACKET - compressor | 2 | |
| 7 | 55-7339 | NUT - compressor | 4 | |
| 8 | 55-7085 | FLATWASHER | 4 | |
| 9 | 503-349 | CLAMP - run capacitator | 1 | |
| 55-7664 | SCREW - clamp | 1 | ||
| 55-7861 | LOCKWASHER | 1 | ||
| 55-7368 | FLATWASHER | 1 | ||
| 10 | 91-7846 | NAMEPLATE - R407C | 1 | |
| 11 | 99-7834 | NAMEPLATE - Caution, High Voltage | 1 |
