Установкa Thermo King схема EVAPORATOR MOUNTING – 226F4
Обновление от: 6/24/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1495 | COIL - evaporator | 1 | |
| 99-6968 | STRIP - sealing (0.12 x 1 x 50 ft) | A/R | ||
| 33-3216 | EXTRUSION - rubber (cut to 6.0 in) | A/R | ||
| 55-1587 | SCREW - coil | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 2 | 99-7803 | NUTSTRIP - coil | 4 | |
| 55-1714 | RIVET - nutstrip | 8 | ||
| 3 | 92-1286 | BRACKET - coil (curbside) | 1 | |
| 4 | 92-1285 | BRACKET - coil (roadside) | 1 | |
| 55-2969 | SCREW - bracket | 6 | ||
| 55-2959 | LOCKWASHER | 6 | ||
| 55-2958 | FLATWASHER | 6 | ||
| 55-8976 | INSERT | 6 |
