Установкa Thermo King схема FRONT PANEL - CONTROL BOX – 226C7
Обновление от: 5/30/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3194 | PANEL - front (AP) | 1 | |
| 92-524 | PANEL - front (EMEIA) | 1 | ||
| 2 | 33-3275 | GASKET - panel | 1 | |
| 3 | 55-3491 | SCREW - panel | 2 | |
| 55-8423 | WASHER - belleville | 2 | ||
| 4 | 55-5432 | WASHER - retainer | 2 | |
| 5 | 41-7872 | SOLENOID - fan | 1 | |
|
10-41-7872 | Реле вентилятора, UT-800/1200 / UTS | 5 400 ₽ |
|
| 55-3491 | SCREW - solenoid | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 6 | 41-4474 | HARNESS - switch | 1 | |
|
10-41-4474 | Выключатель и проводкой | 9 260 ₽ |
|
| 41-4644 | SWITCH - on/off | 1 | ||
| 41-4644 OEM | Выключатель основной, MD/T-Series | 5 370 ₽ |
|
|
| 7 | 91-8376 | NAMEPLATE - On/Off | 1 | |
| 8 | 41-3737 | RECEPTACLE - power (380/3/50) | 1 | |
| 41-1817 | RECEPTACLE - power (230/3/60) | 1 | ||
| 55-3511 | SCREW - receptacle | 4 | ||
| 55-2201 | FLATWASHER | 8 | ||
| 55-2202 | LOCKWASHER | 4 | ||
| 55-2990 | NUT | 4 | ||
| 9 | 92-525 | COVER - dust | 1 | |
| 10 | 99-2664 | NAMEPLATE - 380VAC 50 Hz/460VAC 60 Hz | 1 | |
| 91-1920 | NAMEPLATE - 208-230/3/60 | 1 |
