Установкa Thermo King схема UNDERMOUNT CONDENSER (S20, 24V) – 225H6
Обновление от: 4/28/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2365 | COIL - condenser (undermount) | 1 | |
| 55-8990 | ADAPTER - tube | 1 | ||
| 61-2486 | ADAPTER - outlet, ors | 1 | ||
| 55-3295 | FITTING - saddle | 1 | ||
| 55-9443 | NUT - captive | 6 | ||
| 2 | 92-6812 | BRACKET | 2 | |
| 55-5130 | RIVET - bracket | 4 | ||
| 3 | 98-7997 | FRAME - condenser | 1 | |
| 55-9443 | NUT - captive | 13 | ||
| 4 | 41-8122 | HARNESS - condenser fan | 1 | |
| 33-432 | GROMMET (3/4 id) | 1 | ||
| 5 | 78-1022 | FAN - condenser (24V) | 1 | |
| 55-6994 | SCREW - fan | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 55-6995 | FLATWASHER | 8 | ||
| 55-9443 | NUT - captive | 8 | ||
| 6 | 98-5269 | HOUSING - fans | 2 | |
| 55-6994 | SCREW - housing | 19 | ||
| 55-7170 | LOCKWASHER | 19 | ||
| 55-6995 | FLATWASHER | 19 | ||
| 55-5084 | SCREW - condenser | 4 | ||
| 55-2958 | FLATWASHER | 4 | ||
| 55-4954 | NUT | 4 | ||
| 7 | 41-5069 | SWITCH - high pressure cutout | 1 | |
| 41-5070 | SWITCH | 1 | ||
| 8 | 99-3281 | MOUNT - cable tie | 8 | |
| 9 | 66-7392 | VALVE - relief (see 119B8) | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
