Установкa Thermo King схема DRIVE KIT (MAN TG-L, 12140438) – 225C1
Обновление от: 6/2/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 2 | 22-1053 | CONNECTOR - compressor (horizontal) | 1 | |
|
10-22-1053 | Коллектор компрессора TM-15/16/21 | 1 950 ₽ |
|
| 3 | 108-2397 | SPACER (set) | 1 | |
| 108-1391 | SCREW - compressor | 5 | ||
| 108-1517 | NUT | 5 | ||
| 4 | 108-505 | BRACKET - compressor | 1 | |
| 108-1388 | SCREW - bracket | 2 | ||
| 108-1545 | LOCKWASHER | 2 | ||
| 5 | 108-871 | IDLER - eccentric | 1 | |
| 108-1417 | SCREW - arm | 1 | ||
| 108-1550 | LOCKWASHER | 1 | ||
| 6 | 108-385 | PULLEY - idler | 1 | |
| 108-1365 | SCREW - pulley | 1 | ||
| 108-1539 | LOCKWASHER | 1 | ||
| 7 | 108-735 | BRACKET - restraining | 1 | |
| 108-2398 | SCREW - bracket | 1 | ||
| 8 | NSS | HUB - fan (use original, not supplied by TK) | 1 | |
| 9 | 108-2517 | PULLEY - crankshaft | 1 | |
| 108-1490 | SCREW - pulley & hub | 6 | ||
| 10 | 108-157 | BELT | 1 |
