Установкa Thermo King схема HOSE & FITTINGS KIT FOR X COMPRESSOR – 224D2
Обновление от: 9/11/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-3166 | O-RING | 2 | |
| 2 | 55-9770 | FITTING - suction (#20, straight) | A/R | |
| 3 | 55-9773 | FITTING - suction (#20, elbow, 45 deg) | A/R | |
| 4 | 55-9776 | FITTING - suction (#20, elbow, 90 deg) | A/R | |
| 5 | 61-2183 | HOSE (#20) | A/R | |
| 6 | 33-3165 | O-RING | 2 | |
| 7 | 55-9769 | FITTING - discharge (#16, straight) | A/R | |
| 8 | 55-9772 | FITTING - discharge (#16, elbow, 45 deg) | A/R | |
| 9 | 55-9775 | FITTING - discharge (#16, elbow, 90 deg) | A/R | |
| 10 | 61-2152 | HOSE (#16) | A/R |
