Установкa Thermo King схема TUBE COOLING – 224C3
Обновление от: 10/24/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-9369 | ADAPTER - inlet | 1 | |
| 2 | 55-9186 | FLANGE | 2 | |
| 55-5427 | SCREW - flange | 4 | ||
| 3 | 92-4015 | BRACKET - adapters | 1 | |
| 55-6994 | SCREW - bracket | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 4 | 61-4064 | TUBE | 1 | |
| 5 | 66-4553 | FITTING - saddle | 1 | |
| 6 | 41-5220 | SWITCH - hpco | 1 | |
| 7 | 61-4066 | TUBE (narrow unit) | 1 | |
| 61-4065 | TUBE (wide unit) | 1 | ||
| 8 | 55-9229 | TEE (5/8 x 5/8 x 7/8) | 1 | |
| 9 | 61-4067 | TUBE | 1 | |
| 10 | 61-4068 | TUBE | 1 | |
| 11 | NSS | CONDENSER - standard (see 224B8) | 2 | |
| 12 | 61-3040 | TUBE | 1 | |
| 13 | 61-3041 | TUBE | 1 | |
| 14 | 67-2315 | TANK - receiver | 1 | |
| 15 | 55-2688 | CLAMP - tank & filter | 3 | |
| 16 | 61-4069 | TUBE | 1 | |
| 17 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 33-1015 | O-RING | 1 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 18 | 66-2104 | VALVE - shut-off | 2 | |
| 55-6994 | SCREW - valve | 3 | ||
| 55-7170 | LOCKWASHER | 3 | ||
| 55-7075 | FLATWASHER | 3 | ||
| 51-290 | NUT - captive | 3 | ||
| 19 | 61-4070 | TUBE | 1 | |
| 20 | 55-6396 | NUT - shoulder | 2 | |
| 21 | 55-6356 | SHOULDER | 2 | |
| 22 | 33-672 | O-RING | 2 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 23 | 66-9352 | FILTER - drier | 1 | |
| 66-9352 OEM | Фильтр-осушитель | 6 350 ₽ |
|
|
| 24 | 66-9913 | TUBE | 1 | |
| 25 | 66-9856 | INDICATOR - liquid | 1 | |
| 26 | 61-4071 | TUBE | 1 | |
| 27 | 61-4072 | TUBE (narrow unit) | 1 | |
| 61-4078 | TUBE (wide unit) | 1 | ||
| 28 | 61-1079 | FITTING - assembly | 1 | |
| 55-5130 | RIVET - fitting | 4 | ||
| 29 | 92-120 | INSERT - plug | 1 | |
| 30 | 33-1461 | O-RING | 2 | |
| 31 | 92-121 | NUT | 1 | |
| 32 | 55-7142 | TEE (3/8 x 3/8 x 5/8) | 1 | |
| 33 | 61-4073 | TUBE (narrow unit) | 1 | |
| 61-4079 | TUBE (wide unit) | 1 | ||
| 34 | 61-4074 | TUBE (narrow unit) | 1 | |
| 61-4080 | TUBE (wide unit) | 1 | ||
| 35 | 67-2316 | COIL - evaporator, curbside (S1000, see 224C4) | 1 | |
| 67-2318 | COIL - evaporator/heater, curbside (S1000, see 224C5) | 1 | ||
| 67-2320 | COIL - evaporator, curbside (S960, see 224C4) | 1 | ||
| 67-2322 | COIL - evaporator/heater, curbside (S960, see 224C5) | 1 | ||
| 36 | 67-2317 | COIL - evaporator, roadside (S1000, see 224C4) | 1 | |
| 67-2319 | COIL - evaporator/heater, roadside (S1000, see 224C5) | 1 | ||
| 67-2321 | COIL - evaporator, roadside (S960, see 224C4) | 1 | ||
| 67-2323 | COIL - evaporator/heater, roadside (S960, see 224C5) | 1 | ||
| 37 | 61-4075 | TUBE (narrow unit) | 1 | |
| 61-4081 | TUBE (wide unit) | 1 | ||
| 38 | 55-6975 | CLAMP - tube | 1 | |
| 55-7027 | SCREW - clamp | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 51-290 | NUT - captive | 1 | ||
| 39 | 92-6379 | HOLDER - tube | 1 | |
| 55-5130 | RIVET - holder | 4 | ||
| 40 | 61-4076 | TUBE | 1 | |
| 41 | 61-4077 | TUBE | 1 | |
| 42 | 55-9370 | ADAPTER - outlet | 1 | |
| 43 | 91-3542 | TUBE - rubber | A/R | |
| 44 | 92-2015 | TUBE - rubber | A/R |
