Установкa Thermo King схема TUBES - INSIDE – 224A2
Обновление от: 5/23/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-4048 | TUBE - from interface | 1 | |
| 2 | 91-758 | CLAMP - tube | 3 | |
| 55-8993 | SCREW - clamp | 3 | ||
| 55-8893 | FLATWASHER | 4 | ||
| 55-6996 | LOCKWASHER | 3 | ||
| 55-7042 | NUT | 2 | ||
| 3 | 61-4049 | TUBE - to evaporator | 1 | |
| 4 | 55-6396 | NUT - shoulder | 1 | |
| 5 | 55-6356 | SHOULDER | 1 | |
| 6 | 33-1223 | O-RING | 1 | |
| 7 | 51-1664 | SHOULDER | 2 | |
| 8 | 33-3166 | O-RING | 3 | |
| 9 | 55-5935 | NUT - shoulder | 3 | |
| 10 | 61-4050 | ELBOW | 1 | |
| 11 | 306-1395 | ELIMINATOR - vibration | 1 | |
| 12 | 61-4244 | ELBOW | 1 | |
| 13 | 61-4052 | ELBOW | 1 | |
| 14 | 55-8373 | ADAPTER - bulkhead (#20, ORS) | 1 | |
| 15 | 61-2887 | TUBE | 1 | |
| 203-428 | TAPE - cork | A/R | ||
| 16 | 55-6020 | CLAMP | 2 | |
| 305-1656 | SCREW - clamp | 2 | ||
| 55-6996 | LOCKWASHER | 2 | ||
| 17 | 66-3615 | FITTING - saddle | 1 | |
| 18 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 19 | 55-665 | TEE | 1 | |
| 20 | 11-2886 | VALVE - pressure | 1 | |
| 11-7777 | CORE - valve | 1 | ||
| 55-5672 | CAP - valve | 1 | ||
| 21 | 55-7213 | BODY - valve | 3 | |
| 22 | 44-4258 | SWITCH - lpco | 1 | |
| 23 | 61-2880 | TUBE | 1 | |
| 24 | 61-2881 | TUBE | 1 | |
| 203-428 | TAPE - cork | A/R | ||
| 25 | 102-829 | COMPRESSOR (see 219H7) | 2 | |
| 26 | 55-1122 | ELBOW | 2 | |
| 27 | 61-2889 | TUBE | 1 | |
| 28 | 61-2879 | TUBE | 1 | |
| 29 | 66-1296 | INDICATOR - liquid | 1 | |
| 30 | 61-2878 | TUBE | 1 | |
| 31 | 55-3251 | TEE (3/8 x 3/8 x 3/8) | 1 | |
| 32 | 61-2876 | TUBE | 1 | |
| 33 | 61-2877 | TUBE | 1 | |
| 34 | 61-2888 | TUBE | 1 | |
| 35 | 55-373 | NUT - tube | 1 | |
| 36 | 61-2882 | TUBE | 1 | |
| 37 | 61-2885 | TUBE | 1 | |
| 38 | 61-413 | VALVE - check | 2 | |
| 39 | 61-2883 | TUBE | 1 | |
| 40 | 61-2884 | TUBE | 1 | |
| 41 | 61-2886 | TUBE | 1 | |
| 42 | 91-2473 | CLAMP - tube | 2 | |
| 305-1652 | SCREW - clamp | 2 | ||
| 55-6996 | LOCKWASHER | 2 | ||
| 43 | 66-3570 | FITTING - saddle | 2 | |
| 44 | 41-8057 | SWITCH - modulation | 1 | |
| 45 | 41-1502 | SWITCH - hpco | 1 | |
| 46 | 55-7537 | ADAPTER - bulkhead (#20, ORS) | 1 | |
| 47 | 55-5939 | SHOULDER | 1 | |
| 48 | 61-4053 | ELBOW | 1 | |
| 49 | 306-1397 | ELIMINATOR - vibration | 1 | |
| 50 | 61-4054 | TUBE | 1 | |
| 51 | 61-4055 | TUBE | 1 | |
| 52 | 55-7013 | CLAMP - tube | 3 | |
| 55-8993 | SCREW - clamp | 3 | ||
| 55-8893 | FLATWASHER | 6 | ||
| 55-6996 | LOCKWASHER | 3 | ||
| 55-7042 | NUT | 3 | ||
| 53 | 61-4051 | ELBOW | 1 |
