Установкa Thermo King схема DRIVE KIT (Volkswagen Crafter TDI 2.5 Euro4, 740012) – 223F4
Обновление от: 9/17/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2484 | BELT | 1 | |
| 2 | 108-2438 | CLUTCH | 1 | |
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 1 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 1 | ||
| 3 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1400 | SCREW - compressor (M10X65) | 2 | ||
| 108-1390 | SCREW - compressor (M10X35) | 2 | ||
| 108-1517 | NUT | 2 | ||
| 4 | 108-2479 | SPACER | 3 | |
| 5 | 108-1234 | CONECTOR - swivel | 1 | |
| 33-566 | O-RING | 2 | ||
| 6 | 108-2485 | SUPPORT - compressor | 1 | |
| 108-1407 | SCREW - support (M10X100) | 1 | ||
| 108-1403 | SCREW - support (M10X75) | 2 | ||
| 108-1545 | LOCKWASHER | 2 | ||
| 7 | 108-2486 | SPACER (9mm) | 2 | |
| 108-2521 | SPACER (5mm) | 1 | ||
| 8 | 108-2487 | BRACKET | 1 | |
| 108-1386 | SCREW - bracket (M10X25) | 1 | ||
| 108-1395 | SCREW - bracket (M10X50) | 1 | ||
| 108-1545 | LOCKWASHER | 2 | ||
| 9 | 108-2488 | BRACKET - restraining | 1 | |
| 108-1390 | SCREW - bracket | 4 | ||
| 108-1540 | FLATWASHER | 4 | ||
| 10 | 108-2490 | PULLEY - idler | 1 | |
| 108-1498 | SCREW - idler | 1 | ||
| 11 | 108-2489 | SPACER | 1 |
