Установкa Thermo King схема DRIVE KIT (Nissan Cabstar ZD30 F91A, 740009) – 223F1
Обновление от: 10/8/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2470 | BELT | 1 | |
| 2 | 108-2469 | CLUTCH | 1 | |
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 1 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 1 | ||
| 3 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1410 | SCREW - compressor | 2 | ||
| 108-1517 | NUT | 2 | ||
| 4 | 20-193 | KIT - swivel manifold (incl manifold bracket & screw) | A/R | |
| 5 | 108-2468 | BRACKET - compressor (upper) | 1 | |
| 6 | 108-2467 | BRACKET - compressor (lower) | 1 | |
| 7 | NSS | BRACKET - AC (108-2676, not supplied by TK) | 1 |
