Установкa Thermo King схема DRIVE KIT (Volkswagen Caddy 2.0 SDI, 740002) – 221F6
Обновление от: 5/25/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2607 | CLUTCH (2A 12VDC) | 1 | |
| 2 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1410 | SCREW - compressor | 2 | ||
| 108-1517 | NUT | 2 | ||
| 3 | 108-2413 | SPACER - compressor | 2 | |
| 4 | 108-2414 | SUPPORT - hose | 1 | |
| 108-1388 | SCREW - support | 1 | ||
| 108-1517 | NUT | 3 | ||
| 5 | 92-3842 | CLAMP | 1 | |
| 108-1354 | SCREW - clamp | 1 | ||
| 108-1513 | NUT | 1 | ||
| 6 | 108-2416 | SUPPORT - idler | 1 | |
| 108-1366 | SCREW - support | 2 | ||
| 7 | 108-397 | PULLEY - idler | 1 | |
| 108-1366 | SCREW - pulley | 1 | ||
| 108-1539 | LOCKWASHER | 1 | ||
| 8 | 108-2415 | BELT | 1 |
