Установкa Thermo King схема DRIVE KIT (Fiat doblo 1.3 JTD, 12140453) – 221A7
Обновление от: 12/7/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2646 | CLUTCH (12V poly-V 6KD 120 dia) | 1 | |
| 2 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1391 | SCREW - compressor | 4 | ||
| 108-1517 | NUT | 4 | ||
| 3 | 108-1234 | CONNECTOR - compressor (horizontal) | 1 | |
| 33-566 | O-RING | 2 | ||
| 108-1498 | SCREW - connector | 1 | ||
| 4 | 108-2368 | BELT (poly-V 6PK1450) | 1 | |
| 5 | 108-397 | PULLEY - idler | 1 | |
| 108-1365 | SCREW - idler | 1 | ||
| 108-1539 | LOCKWASHER | 1 | ||
| 6 | 108-2365 | BRACKET - compressor | 1 | |
| 108-1366 | SCREW - bracket (M8 x 30) | 2 | ||
| 108-1368 | SCREW - bracket (M8 x 40) | 2 | ||
| 108-1539 | LOCKWASHER | 4 | ||
| 7 | 108-2366 | SPACER - bracket | 1 | |
| 8 | 108-2367 | SUPPORT - hose | 1 | |
| 9 | 91-7168 | CLAMP - hose | 1 | |
| 108-1355 | SCREW - clamp | 1 | ||
| 108-1513 | NUT | 1 |
