Установкa Thermo King схема AIR INLET MODULE – 216C3
Обновление от: 9/22/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7658 | ROOF | 1 | |
| 51-1452 | NUT - self clinch | 2 | ||
| 55-2988 | RIVET | 34 | ||
| 55-7752 | SCREW - roof | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 2 | 92-6014 | PANEL - service | 1 | |
| 3 | 92-6015 | PANEL - service | 1 | |
| 4 | 51-667 | FASTENER - panel | 9 | |
| 5 | 51-668 | RIVET - fastener | 9 | |
| 6 | 92-6016 | INSULATION | 1 | |
| 7 | 33-3864 | STRIP - polyester | A/R | |
| 8 | 92-6017 | INSULATION | 1 | |
| 9 | 99-3281 | MOUNT - bandwrap | 3 | |
| 51-256 | RIVET - mount | 3 | ||
| 55-2330 | BANDWRAP | 3 | ||
| 10 | 33-3931 | STRIP - polyester | A/R |
