Установкa Thermo King схема BELT & PULLEY GROUP – 212F8
Обновление от: 10/13/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2850 | PULLEY - flywheel | 1 | |
| 55-9822 | SCREW - pulley | 6 | ||
| 55-5411 | LOCKWASHER | 6 | ||
| 203-400 | SEALER - thread | A/R | ||
| 2 | 78-1484 | BELT - compressor & alternator (poly groove) | 1 | |
| 10-78-1484 | Ремень, TriPac | 4 440 ₽ |
|
|
| 3 | 77-2846 | PULLEY - idler | 1 | |
| 51-1244 | SCREW - pulley | 1 | ||
| 55-365 | LOCKWASHER | 1 | ||
| 4 | 92-5014 | BRACKET - idler pulley | 1 | |
| 51-1247 | SCREW - bracket | 1 | ||
| 55-6283 | LOCKWASHER | 1 | ||
| 55-7072 | FLATWASHER | 1 | ||
| 5 | 77-2845 | PULLEY - alternator | 1 | |
| 6 | 77-2855 | FAN - alternator (ccw directional) | 1 | |
| 7 | 40-929 | ALTERNATOR (65 amp, see 209C5) | 1 | |
|
10-45-2590 | Генератор 65A, UT800/1200 | 13 870 ₽ |
|
|
10-41-6781 | Генератор 65A, SB-XXX/SMX/SMX-II/SL/SLe/SLX/SLXe SB-II/III | 13 840 ₽ |
|
| 51-1246 | SCREW - alternator | 1 | ||
| 55-4625 | FLATWASHER | 2 | ||
| 55-7005 | NUT | 1 | ||
| 8 | 92-5011 | BRACKET - alternator | 1 | |
| 55-129 | SCREW - bracket (1-1/4 lg) | 2 | ||
| 55-3641 | SCREW - bracket (1-3/4 lg) | 1 | ||
| 55-375 | LOCKWASHER | 3 | ||
| 55-402 | FLATWASHER | 6 | ||
| 55-289 | NUT | 3 | ||
| 9 | 92-5009 | BRACKET - compressor (front) | 1 | |
| 55-129 | SCREW - bracket | 4 | ||
| 55-402 | FLATWASHER | 8 | ||
| 55-5078 | NUT | 4 | ||
| 10 | 92-5173 | BRACKET - compressor (rear) | 1 | |
| 11 | 92-5013 | BRACKET - compressor bracket to engine | 1 | |
| 55-129 | SCREW - bracket (3/8) | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 55-5078 | NUT | 2 | ||
| 12 | 92-5058 | SHIM - compressor | 1 | |
| 13 | 102-1018 | COMPRESSOR - 15HD (see 169C2, w/o manifold) | 1 | |
| 102-1004 | COMPRESSOR - 15HD (see 169C2, w/o manifold) | 1 | ||
| 14 | 107-311 | CLUTCH (12V, 4.62 in, poly groove, 8V) | 1 | |
|
10-107-261 | Муфта электромагнитная, 8PV/12V, TM13/15/16, QP13/15/16 | 7 740 ₽ |
|
| 203-544 | OIL - compressor (8 oz) | A/R | ||
| 55-3641 | SCREW - compressor | 4 | ||
| 55-402 | FLATWASHER | 8 | ||
| 55-5078 | NUT | 4 | ||
| 15 | 92-5030 | BARREL - turnbuckle | 1 | |
| 55-1587 | SCREW - alternator | 4 | ||
| 55-5075 | SCREW - compressor | 4 | ||
| 55-3686 | NUT - compressor | 4 | ||
| 16 | 55-5075 | SCREW - engine mount | 4 | |
| 17 | 55-5871 | WASHER - special | 4 | |
| 55-2038 | FLATWASHER | 4 | ||
| 18 | 91-2338 | MOUNT - engine | 4 | |
|
10-91-2338 | Подушка двигателя, CD/JD/KD/MD-II | 3 020 ₽ |
|
| 19 | 55-3686 | NUT | 4 | |
| 20 | 92-5008 | MOUNT - engine (front) | 1 | |
| 20-92-5008 | Опора | 28 510 ₽ |
|
|
| 21 | 92-5010 | MOUNT - engine (rear) | 1 | |
| 20-92-5010 | Опора | 28 000 ₽ |
|
|
| 55-9727 | SCREW - mount | 8 | ||
| 55-1173 | LOCKWASHER | 8 | ||
| 55-4625 | FLATWASHER | 8 | ||
| 55-7069 | FLATWASHER (8.4 mm) | 1 | ||
| 55-790 | LOCKWASHER (8.1 mm) | 1 | ||
| 51-1218 | SCREW (M8 x 30 mm) | 1 |
