Установкa Thermo King схема FAN – 210G4
Обновление от: 2/13/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7448 | BRACKET - fan | 1 | |
| 55-7340 | SCREW - bracket to base & heater | 6 | ||
| 55-7404 | LOCKWASHER | 6 | ||
| 55-7089 | FLATWASHER | 6 | ||
| 51-190 | NUT - bracket to base | 2 | ||
| 2 | 78-1520 | FAN | 4 | |
| 55-8956 | SCREW - fan to bracket | 16 | ||
| 55-7368 | FLATWASHER | 16 | ||
| 55-7665 | NUT | 16 | ||
| 3 | 41-4949 | CONNECTOR | 4 |
