Установкa Thermo King схема CONNECTOR KIT – 210D8
Обновление от: 1/26/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-5296 | FRAME - fixing | 1 | |
| 2 | 41-5523 | COVER - connector, female | 4 | |
| 3 | 41-5524 | COVER - connector, female | 1 | |
| 4 | 41-5929 | COVER - connector, female | 1 | |
| 41-5527 | PIN - female contact, 14 awg | 2 | ||
| 41-5552 | PIN - female contact, 16 awg | 9 | ||
| 41-7178 | PIN - female contact, 20 awg | 4 | ||
| 41-7177 | PIN - female contact | 9 | ||
| 41-7145 | PIN - female, 4 mm, sqr | 3 |
