Установкa Thermo King схема BLOWER – 210D6
Обновление от: 10/23/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-5522 | CHANNEL - duct, weld | 1 | |
| 55-7035 | SCREW - channel to frame | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 51-290 | NUT - captive | 4 | ||
| 2 | 78-1516 | HOUSING - blower | 1 | |
| 55-7035 | SCREW - housing to channel | 10 | ||
| 55-7170 | LOCKWASHER | 10 | ||
| 55-7075 | FLATWASHER | 10 | ||
| 51-290 | NUT - captive | 10 | ||
| 3 | 78-1517 | BLOWER | 1 | |
| 55-7172 | SCREW - blower | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 4 | 78-1518 | RING - inlet | 1 | |
| 55-7067 | SCREW - ring | 6 | ||
| 5 | 55-9992 | BUSHING - cable | 1 | |
| 55-9998 | LOCKNUT - bushing | 1 | ||
| 6 | 40-974 | SENSOR - temperature | 1 | |
|
40-974 OEM | Датчик температуры калиброванный | 8 770 ₽ |
|
|
10-40-974 | Датчик температуры калиброванный | 3 500 ₽ |
|
| 7 | 92-4880 | INSULATION | 1 | |
| 8 | 92-5523 | INSULATION | 1 | |
| 9 | 99-6968 | STRIP - neoprene (50 ft cut to length) | A/R |
