Установкa Thermo King схема KIT CAB INSIDE – 207H2
Обновление от: 2/10/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3967 | DUCTING - in | 1 | |
| 2 | 61-2744 | TUBE - perforated | 1 | |
| 3 | 61-2746 | HOSE - textile | 1 | |
| 4 | 92-3969 | DUCTING - end | 1 | |
| 5 | 92-3968 | OUTLET - air | 2 | |
| 6 | 92-2750 | DIFFUSER - air | 1 | |
| 7 | 92-4441 | UNDERLAY - ducting end | 1 | |
| 8 | 92-4440 | UNDERLAY - ducting in | 1 | |
| 9 | 51-1131 | SCREW - diffuser | 3 | |
| 10 | 51-901 | SCREW - ducting & protection | 8 | |
| 11 | 55-2331 | BANDWRAP | 2 | |
| 12 | 41-6382 | ClimaAIRE | 1 | |
| 13 | 92-4559 | UNDERLAY - ClimaAIRE | 1 | |
| 14 | 55-8382 | SCREW - ClimaAIRE | 4 | |
| 15 | 55-8410 | FLATWASHER | 4 | |
| 16 | 55-9057 | LOCKWASHER | 4 | |
| 17 | 55-7749 | NUT - ClimaAIRE | 4 | |
| 18 | 92-3972 | PROTECTION - return air | 1 | |
| 19 | 92-4560 | ELBOW | 1 | |
| 20 | 55-2688 | CLAMP | 1 |
