Установкa Thermo King схема COMPRESSOR GROUP (KITS 700043, 700044 & 700045) – 203E5
Обновление от: 5/13/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-869 | COMPRESSOR - FKX40/470 (see 203F1) | 1 | |
| 2 | 107-321 | CLUTCH - LA16.172 (700043) | 1 | |
| 107-317 | CLUTCH - LA16.156 (700044) | 1 | ||
| 107-319 | CLUTCH - LA16.168 (700045) | 1 | ||
| 3 | 55-2505 | ELBOW | 1 | |
| 4 | 55-308 | ELBOW | 1 | |
| 5 | 61-2724 | FITTING - L flare | 2 | |
| 6 | 33-768 | GASKET | 5 | |
| 7 | 55-9582 | VALVE | 2 | |
| 8 | 41-4146 | SWITCH - hpco (for connectors see 115D14) | 1 | |
| 9 | 41-4147 | SWITCH - lpco (for connectors see 115D14) | 1 | |
| 10 | 41-3345 | SENSOR - temperature (for connectors see 115D14) | 1 | |
| 11 | 41-6198 | HARNESS - compressor (for connectors see 115D14) | 1 | |
| 12 | 44-9607 | CONNECTOR - female | 1 |
