Установкa Thermo King схема DRIVE KIT (Renault Mascott, 12140311) – 200H0
Обновление от: 6/2/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-221 | BELT | 1 | |
| 2 | 108-659 | PLATE - front | 1 | |
| 108-1390 | SCREW - plate | 4 | ||
| 108-1545 | LOCKWASHER | 4 | ||
| 3 | 108-904 | IDLER - eccentric | 1 | |
| 108-1421 | SCREW - idler | 1 | ||
| 108-1550 | LOCKWASHER | 1 | ||
| 4 | 108-397 | PULLEY - idler | 1 | |
| 108-1365 | SCREW - pulley | 1 | ||
| 108-1539 | LOCKWASHER | 1 | ||
| 5 | N/A | BRACKET (not supplied by Thermo King) | 1 | |
| 6 | N/A | HOSE (not supplied by Thermo King) | 2 | |
| 7 | 108-101 | CLAMP - hose | 4 | |
| 8 | N/A | PULLEY - crankshaft (not supplied by Thermo King) | 1 | |
| 9 | N/A | ALTERNATOR (not supplied by Thermo King) | 1 | |
| 108-1396 | SCREW - alternator (M10 x 50) | 1 | ||
| 108-1408 | SCREW - alternator (M10 x 100) | 1 | ||
| 108-1545 | LOCKWASHER | 2 | ||
| 10 | 108-483 | BRACKET - compressor | 1 | |
| 108-1387 | SCREW - bracket (M10 x 25) | 1 | ||
| 108-1388 | SCREW - bracket (M10 x 30) | 4 | ||
| 108-1545 | LOCKWASHER (M10) | 5 | ||
| 108-1517 | NUT (M10) | 1 | ||
| 108-1416 | SCREW - bracket (M12 x 30) | 1 | ||
| 108-1550 | LOCKWASHER (M12) | 2 | ||
| 11 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1392 | SCREW - compressor | 4 | ||
| 108-1545 | LOCKWASHER | 4 | ||
| 108-1517 | NUT | 4 | ||
| 12 | 22-1053 | CONNECTOR - compressor (horizontal) | 1 | |
|
10-22-1053 | Коллектор компрессора TM-15/16/21 | 1 950 ₽ |
|
| 33-566 | O-RING | 2 | ||
| 13 | 108-1649 | CLUTCH - compressor (D.194 POLY-V 12V) | 1 | |
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 1 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 1 |
