Установкa Thermo King схема DRIVE KIT (Mercedes Sprinter 208/311/313CDI, 12140323) – 200F6
Обновление от: 9/2/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-257 | BELT - compressor | 1 | |
| 2 | 108-1305 | CLUTCH - compressor (180 dia, poly-V 6K) | 1 | |
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 1 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 1 | ||
| 3 | NSS | COMPRESSOR (see compressor section) | 1 | |
| 108-1502 | SCREW - compressor | 4 | ||
| 108-1540 | FLATWASHER | 4 | ||
| 108-1517 | NUT | 4 | ||
| 4 | 108-1234 | FITTING - swivel | 1 | |
| 33-566 | O-RING | 2 | ||
| 5 | 108-1505 | SCREW - fitting | 1 | |
| 6 | 108-946 | SPACER | 2 | |
| 7 | 108-806 | BRACKET - compressor (rear) | 1 | |
| 108-1371 | SCREW - bracket | 3 | ||
| 108-1534 | LOCKWASHER | 3 | ||
| 108-1534 | FLATWASHER | 3 | ||
| 8 | 108-784 | BRACKET - compressor (front) | 1 | |
| 108-1366 | SCREW - bracket (M8 x 30) | 1 | ||
| 108-1368 | SCREW - bracket (M8 x 40) | 1 | ||
| 108-1539 | LOCKWASHER | 2 |
