Установкa Thermo King схема HOSE GROUP – 200E3
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - TM16-XD (see 179A7) | 1 | |
| NSS | COMPRESSOR - TM15-XD/HD (see 169C2) | 1 | ||
| NSS | COMPRESSOR - TM13-XD (see 189C3) | 1 | ||
| 102-589 | COMPRESSOR - TM08-XD (2A, 12V) | 1 | ||
| 203-515 | OIL - compressor (1 liter) | A/R | ||
| 203-505 | OIL - compressor (8 oz) | A/R | ||
| 2 | 67-1782 | HOSE - refrigeration (#4, see 165D6) | A/R | |
| 3 | 67-1708 | HOSE - refrigeration (#6) | A/R | |
| 4 | 67-1709 | HOSE - refrigeration (#8) | A/R | |
| 5 | 67-1711 | HOSE - refrigeration (#12) | A/R | |
| 6 | 33-2350 | O-RING (7/16 id) | 1 | |
| 7 | 33-672 | O-RING (9/16 id) | 1 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 8 | 51-2432 | FITTING - discharge (tube-O, see 165D6) | 1 | |
| 9 | 51-2499 | FITTING - suction (tube-O, see 165D6) | 1 | |
| 10 | 51-2436 | FITTING - liquid & defrost (90 deg, #6) | 3 | |
| 11 | 51-2423 | FITTING - discharge (90 deg, #8) | 1 | |
| 12 | 51-2488 | FITTING - suction (90 deg, #12 hose, #10 fitting) | 1 | |
| 13 | 33-1461 | O-RING (5/16 id, #4) | 1 | |
| 14 | 33-1015 | O-RING (3/8 id, #6) | 3 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 15 | 33-566 | O-RING (1/2 id, #8) | 1 | |
| 16 | 51-2492 | FITTING - expansion valve | 1 | |
| 17 | 55-9987 | FITTING - suction (#12) | 1 | |
| 18 | 33-1222 | O-RING (3/4 id, #12) | 3 | |
| 19 | 51-2437 | FITTING - jet cool (90 deg, #4) | 1 | |
| 20 | 51-2425 | SPLICE (#16 hose w/ 7/16-20 charging port) | 1 | |
| 21 | 66-5029 | ORIFICE | 1 | |
| 66-5028 | FILTER | 1 | ||
| 22 | 44-9020 | THERMOSTAT | 1 | |
| 23 | 92-4587 | BRACKET - solenoid | 1 | |
| 55-1384 | SCREW - solenoid | 2 | ||
| 55-7861 | LOCKWASHER | 2 | ||
| 55-7697 | FLATWASHER | 2 | ||
| 24 | 66-5908 | VALVE - pilot (12V) | 1 | |
|
10-66-5908 | Соленоид, KD-II/MD-II/RD-II/SB-III/V-Series | 28 750 ₽ |
|
| 41-5047 | COIL - valve (12V) | 1 | ||
| 25 | 11-9223 | HOSE - drain | A/R | |
| 26 | 55-3359 | CLAMP (7/8 inch) | 5 | |
| 55-2570 | CLAMP (1-3/4 inch) | 5 | ||
| 55-6808 | CLAMP (2 inch) | 2 | ||
| 51-346 | SCREW - clamp | 12 | ||
| 27 | 55-9258 | CONNECTOR - drain (Y) | 1 | |
| 28 | 61-3048 | HOSE - refrigeration (#16) | A/R | |
| 29 | 51-1143 | FITTING - suction (90 deg, #16 hose, #10 fitting) | 1 | |
| 30 | 51-2498 | FITTING - suction (90 deg, #16 hose, #12 fitting) | 2 |
