Установкa Thermo King схема INTERFACE KIT - CCU LONGER – 198G2
Обновление от: 11/2/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6882 | LADDER | 1 | |
| 2 | 51-900 | NUT - captive | 4 | |
| 3 | 51-290 | NUT - captive | 2 | |
| 4 | 92-4533 | SPACER | 2 | |
| 5 | 92-4534 | SPACER | 2 | |
| 6 | 92-4535 | SPACER | 2 | |
| 7 | 92-4536 | FLANGE - return air | 1 | |
| 8 | 92-4537 | INSULATION - return air | 1 | |
| 9 | 61-2742 | TUBE - ducting | 1 | |
| 10 | 61-3014 | TUBE - ducting | 1 | |
| 11 | 92-4442 | LID | 1 | |
| 55-7067 | SCREW - lid | 4 | ||
| 12 | 98-7026 | COVER - weld | 1 | |
| 13 | 98-6884 | COVER - top | 1 | |
| 51-886 | SCREW - top cover | 3 | ||
| 51-290 | NUT - captive | 3 |
