Установкa Thermo King схема V-300 SPECTRUM REFERENCE SHEET – 18U53
Обновление от: 4/8/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 902362 | System - V-300 MAX 30 SPECTRUM | 10/12 | ||
| 902363 | System - V-300 MAX 50 SPECTRUM | 5/12 | ||
| 703338 | Condenser - V-300 MAX 30 SPECTRUM (12V) | 5/12 | ||
| 703339 | Condenser - V-300 MAX 30 SPECTRUM (24V) | 5/12 | ||
| 703361 | Condenser - V-300 MAX 50 SPECTRUM (12V) | 5/12 | ||
| 703362 | Condenser - V-300 MAX 30 SPECTRUM (24V) | 5/12 | ||
| 703342 | 2X ES150 Evaporator (12V) | 10/12 | ||
| 703343 | 2X ES150 Evaporator (24V) | 10/12 | ||
| 703350 | 1X ES150 + 1X ES100 Evaporator (12V) | 10/12 | ||
| 703351 | 1X ES150 + 1X ES100 Evaporator (24V) | 10/12 | ||
| 703353 | 1X ES200 + 1X ES100 Evaporator (12V) | 10/12 | ||
| 703354 | 1X ES200 + 1X ES100 Evaporator (12V) | 10/12 | ||
| 703372 | 2X ES150 EVAP CONFIGURATION 12V | 10/12 | ||
| 703373 | 2X ES150 EVAP CONFIGURATION 24V | 10/12 | ||
| 703375 | 1X ES150 + 1X ES100 EVAP CON 12V | 10/12 | ||
| 703376 | 1X ES150 + 1X ES100 EVAP CON 24V | 10/12 | ||
| 703378 | 1X ES200 + 1X ES100 EVAP CON 12V | 10/12 | ||
| 703379 | 1X ES200 + 1X ES100 EVAP CON 24V | 10/12 | ||
| 085313 | 400/3/50 MAX | 10/12 | ||
| 085315 | 220/1/50 MAX | 10/12 | ||
| 085446 | 230/3/60 MAX | 10/12 | ||
| 085461 | 220/1/60 | 10/12 | ||
| 085475 | 400/3/50 MAX 5-Pin | 10/12 | ||
| 701760 | Discharge Muffler | 10/12 | ||
| 702238 | Compressor - TM15 XD Engine 12V | 10/12 | ||
| 702239 | Compressor - TM15 XD Engine 12V | 10/12 | ||
| 702240 | Compressor - TM15 XD Engine 24V | 10/12 | ||
| 702241 | Compressor - TM15 XD Engine 24V | 10/12 | ||
| 702552 | Extension Harness (2M) | 2/13 | ||
| 703374 | Installation Kit | 10/12 | ||
| 703613 | Extension Harness (4M) | 10/12 | ||
| 703614 | Extension Harness (5M) | 10/12 | ||
| 719260 | Compressor - TM15 XD Engine 12V | 10/12 | ||
| 719261 | Compressor - TM15 XD Engine 24V | 10/12 | ||
| 720272 | Compressor Fittings | 10/12 | ||
| 720781 | Hose Covers | 10/12 | ||
| 720785 | Deflector Cover Small | 10/12 | ||
| 720786 | Deflector Cover Large | 10/12 | ||
| 720818 | Din Adapter Kit | 10/12 | ||
| 720837 | Door Switch Kit | 10/12 |
