Установкa Thermo King схема TRAC-KING SATELLITE 2-WAY RAIL (uP-VI, 720404) – 187H2
Обновление от: 9/24/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 40-826 | KIT - Trac-King Satellite (rail 2-way, uP-VI) | 1 | ||
| 1 | 40-972 | ANTENNA, HARNESS & BRACKET | 1 | |
| 44-8920 | PLUG (6-pin) | 1 | ||
| 55-7843 | SCREW - antenna | 4 | ||
| 55-7031 | FLATWASHER | 4 | ||
| 55-7697 | LOCKWASHER | 4 | ||
| 2 | 92-2754 | BRACKET - antenna | 1 | |
| 3 | 92-2753 | BRACKET - rear | 1 | |
| 4 | 92-2755 | ANGLE - support | 1 | |
| 55-826 | SCREW - bracket | 10 | ||
| 55-411 | FLATWASHER | 16 | ||
| 55-366 | LOCKWASHER | 10 | ||
| 55-291 | NUT | 7 | ||
| 5 | 55-2239 | CLAMP - harness | 1 | |
| 6 | 99-6093 | ANCHOR - bandwrap | A/R | |
| 51-321 | RIVET - anchor | A/R | ||
| 55-2331 | BANDWRAP | A/R | ||
| 7 | 41-5218 | HARNESS - control box | 1 | |
| 8 | 44-8935 | PLUG - power supply (4-pin) | 1 | |
| 9 | 41-5190 | PLUG - iBox (35-pin) | 1 | |
| 41-2457 | TERMINAL - socket | 13 | ||
| 10 | 44-9342 | RECEPTACLE - controller | 1 | |
| 11 | 41-2405 | RECEPTACLE - flash loading (5-pin) | 1 | |
| 12 | 44-8914 | RECEPTACLE - antenna (6-pin) | 1 | |
| 13 | 44-8920 | PLUG - communications harness (6-pin) | 1 | |
| 14 | 44-5537 | SOCKET - relay | 1 | |
| 15 | 41-895 | RELAY - plug in | 2 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 16 | 45-2355 | iBox (2-way, see 191H7) | 1 | |
| 51-320 | SCREW - iBox | 3 | ||
| 55-2998 | LOCKWASHER | 3 | ||
| 55-3013 | FLATWASHER | 3 | ||
| 51-114 | STANDOFF | 3 | ||
| 17 | 41-5217 | HARNESS - switch | 1 | |
| 18 | 41-5329 | SWITCH - push button (green) | 1 | |
| 19 | 41-5330 | SWITCH - push button (red) | 1 | |
| 20 | 41-4163 | SWITCH - on/off | 1 | |
|
30-41-4163 | Выключатель | 5 410 ₽ |
|
| 21 | 41-4165 | SWITCH - on/none/on (satellite) | 1 | |
| 22 | 44-5537 | SOCKET - relay | 1 | |
| 23 | 41-4852 | CONVERTER - power supply (12 to 6V) | 1 | |
| 55-3121 | SCREW - converter | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-2993 | LOCKWASHER | 2 | ||
| 55-4953 | NUT | 2 | ||
| 24 | 92-2751 | NAMEPLATE - Switch & Warning (set) | 1 | |
| 25 | 92-2756 | NAMEPLATE - Warning Satellite Controlled | 1 | |
| 26 | 92-2752 | NAMEPLATE - Switch | 1 | |
| 27 | 33-3369 | RING - seal (switch) | 2 | |
| 44-9340 | SOCKET - gold (18 ga Deutsch) | A/R | ||
| 44-8330 | PIN - gold (18 ga Deutsch) | A/R |
