Установкa Thermo King схема EVAPORATOR BLOWER GROUP – 184D2
Обновление от: 10/3/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 104-710 | MOTOR - blower | 1 | |
| 51-1542 | KEY - motor | 2 | ||
| 55-7825 | NUT - motor | 4 | ||
| 55-7066 | LOCKWASHER | 4 | ||
| 55-6988 | FLATWASHER | 4 | ||
| 2 | 78-1358 | HOUSING - blower (right, cw) | 1 | |
| 3 | 78-1359 | HOUSING - blower (left, ccw) | 1 | |
| 55-6994 | SCREW - housing to frame | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 4 | 78-1332 | WHEEL - blower (ccw) | 1 | |
| 5 | 78-1334 | WHEEL - blower (cw) | 1 | |
| 6 | 78-1331 | RING - inlet | 4 | |
| 7 | 40-974 | KIT - sensor (graded) | 1 | |
|
40-974 OEM | Датчик температуры калиброванный | 8 770 ₽ |
|
|
10-40-974 | Датчик температуры калиброванный | 3 500 ₽ |
|
| 8 | 55-9992 | BUSHING - cable | 1 | |
| 55-9998 | LOCKNUT | 1 | ||
| 9 | 55-9555 | BUSHING - cable | 2 | |
| 55-9559 | LOCKNUT | 2 | ||
| 10 | 55-6010 | PLUG - housing | 2 | |
| 11 | 99-4931 | NAMEPLATE - Arrow | 2 | |
| 12 | 99-9234 | NAMEPLATE - caution, fan | 2 |
